SPARX 18

 Twin Zoom Washbeam

The all-rounder at it's best

Sparx 12

High Performance, Beam, Twin Zoom

.....Just Brilliant

01 / 03

  • 7 RGBW high-performance LEDs of 40 W each, up to 3,500 lm output

  • > 20.000 h life time

  • Flicker-free operation, camera mode: 100, 120 and 600 Hz

  • Zoom range 2.3° – 55° (1:23.9), 2,3° – 33° at ½ peak; 4,4° – 55° at 1/10 peak

  • Highly efficient optics for perfect color mixing

  • Minimal scattered light

  • Encapsulated optical system

  • Individual LED control – Single pixel control

  • Sparkle channel for dynamic effects

  • Multiple layers with independent patterns can be stacked on top of each other

  • Countless color and pattern combinations

  • Separate CTC channel

  • Color temperature accuracy +/- Green shift (Black Body Shift)

  • High-resolution, steplessly variable dimmer 0–100%

  • Color-accurate dimming

  • Electronic strobe with pulse and random effects

  • Basic color temperature of the spotlight infinitely variable: 2700 K, 3200 K, 4200 K, 5600 K, 6000 K, 6500 K, 7000 K or 8000 K as well as variable from 2000 K to 12000 K

  • 3 phase extra strong stepping motors

  • Precise, very fast and silent movement

  • Quick, quiet zoom (maximum angle change 2.3° – 55° in 0.5 s)

  • 540° pan / 234° tilt

  • USITT DMX-512, RDM

  • Ethernet interface with Art-Net, sACN and Kling-Net

  • Wireless DMX / RDM Lumen Radio CRMX TiMo

  • Bluetooth, Wifi

  • Mini USB for software update

  • LCD display with function keys and battery buffer, electronically rotatable

  • Stand-alone mode, master/slave function

  • Built-in DMX analyser

  • Robust, roadworthy design

  • Individually changeable LEDs

  • Fan control for almost noiseless operation, 29 dB(A)

  • Neutrik 5pin XLR IN/OUT

  • RJ45 IN/OUT network socket

  • Power IN/OUT

  • 5pin IN/OUT socket (prepared for battery operation)

  • 2 Omega brackets with Original Camloc® fasteners for quick and convenient installation in any position, with four different fastening options

  • Optional: Diagonal omega bracket for two additional mounting possibilities

  • Max. power consumption 300 VA

  • Input voltage range 100 V–240 V, 50/60 Hz

  • Total heat dissipation (calculated): 1,024 BTU/hr

  • Dimensions: B 331 x D 243 x H 445 mm

  • Weight: 9,8 kg

  • CASE46 Amptown double flight case

  • CASE47 Amptown 4-compartment flight case

  • CASE48 Amptown 6-compartment flight case

  • BLOB02 Omega bracket standard

  • BLOB03 Diagonal omega bracket

Image 23.jpeg
Image 22.jpeg

Maximum zoom (70°)

Minimum zoom (3°)

Sparx9_Zoom_homogene_Ausleuchtung.mp4
Sparx9_Zoom_Streulicht.mp4

Uniform illumination

Beams optimised for scattered light
